Large Aper Roller Bearing Custom For Moderate Speed Tapered Wheel Bearings

Large Aper Roller Bearing Custom For Moderate Speed Tapered Wheel Bearings

    • Large Aper Roller Bearing Custom  For Moderate Speed Tapered Wheel Bearings
    • Large Aper Roller Bearing Custom  For Moderate Speed Tapered Wheel Bearings
  • Large Aper Roller Bearing Custom  For Moderate Speed Tapered Wheel Bearings

    Product Details:

    Place of Origin: China
    Brand Name: TOB Taper Roller Bearings
    Certification: ISO 16949

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiated
    Price: negotiated
    Packaging Details: Cartons or Pallets
    Delivery Time: negotiated
    Payment Terms: T/T
    Supply Ability: negotiated
    Contact Now
    Detailed Product Description
    Material: Hardened High Carbon Chromium Steel Parameters: D=15--d=280 2559-2523B--48286-48220B 11590--544091 350305B--352956 48680DW-777752
    Advanced Materials: Patented Materials Including High TF And Super TF Number Of Row: Single Row Or Double Row
    Application: Commonly Used For Moderate Speed, Heavy Duty Applications Where Durability Is Required Common Real World Applications: In Agriculture, Construction And Mining Equipment, Axle Systems, Gear Box, Engine Motors
    High Light:

    double row taper roller bearing

    ,

    taper rolling bearing

    Large Taper Roller Bearings , Large diameter Taper Roller Bearings , Custom Taper Roller Bearings

    Instruction

    1. The tapered roller bearing is assembled through a rolling element. Guided by the sidewall of an inner ring, it can bear radial load and axial load in one direction.

    2. As a kind of thrust bearing, this product is mostly applied in the car differential, front wheel, rear wheel, machine tool, axle, construction machinery, various vehicle transmission systems, the hoisting and conveying machinery, and more.

    3. The design of modified line contact between a rolling element and a raceway allows the load capacity of our four-row bearings to be effectively enhanced. Rolling mills adopt four-row tapered roller bearings to accommodate impact loads. Bearing rings are manufactured from carburizing steel. The use of pin retainers allows the quantity of rollers to be increased. As a result, rated load can be increased.

    4. The metric and inch bearings have entirely distinct technical standards. Also, they have different requirements for axles and bearing boxes. If you have any doubt, please make contact with our service department.

    Structural Diagram

    Related Names
    Single-Row Tapered Roller Bearing | Bearing For Car Parts | Construction Machinery Bearing

    Parameters

    d=15--d=280 2559-2523B---48286-48220B 11590--544091 350305B--352956 48680DW-777752



    Feature
    These bearings have tapered rollers which are guided by the thicker side of the cup. The design of the sliding surfaces of the cup and inner ring and the rolling elements when extended converge towards the same single point on the bearing axle. bearing tapered
    Single-row bearings can carry radial load and axial load in one direction.
    Double-row and four-row taper roller bearings can bear the radial load and axial load in double directions.


    Cages
    normally there taper roller bearings use pressed basket-shaped cages of steel sheet. But for cages with greater machined dimension, cages are also used.
    Taper Roller Bearings manufactures both metric and inch-sized single row, double-row and four-row taper roller bearings. bearings tapered, taper bearing, tapered roller bearing, taper roller bearing, single row tapered bearing, double row tapered bearing, four row tapered bearing, bearing china tapered, Large Taper roller bearings, Large diameter Taper roller bearings, Custom Taper roller bearings, Large size Taper roller bearings



    Size Range

    Metric Series Bore Diameter (mm)
    32900 10-280
    32000X 10-260
    30200 10-220
    30300 10-190
    32200 10-220
    32300 30-170
    33000 10-150
    33100 10-120
    33200 10-105
    31300 10-150
    Inch Series Outside Diameter (mm)
    30000R ≤400
