    Product Details:

    Place of Origin: China
    Brand Name: TOB Deep Groove Ball Bearings
    Certification: ISO 16949

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiated
    Price: negotiated
    Packaging Details: Cartons or Pallets
    Delivery Time: negotiated
    Payment Terms: T/T
    Supply Ability: negotiated
    Detailed Product Description
    Material: Chrome Steel / GCr15 / Bearing Steel Clearanc: C2, CN, C3, C4, C5
    Type: OPEN, ZZ, 2RS, N, NR, ZN, RZN Application: Office Equipment , Scooter Aluminum Windows , Shower Blocks, Hanging Round, Closet Wheel, Toys, Etc
    Precision Rating: P0/P1/P2/P5/P6 Color: Silvery White

    Deep groove ball bearing 6000 series 6200series 6300series 6400 series

    Deep groove ball bearings are the most commonly used bearings. It's simple, easy to use. Mainly used to bear radial load, but increase the bearing radial clearance, with certain properties of angular contact ball bearings can withstand radial and axial joint load. They should not be used in a high speed thrust ball bearings, can also be used to bear the pure axial load.

    With the same size compared to other types of bearings, such bearings friction coefficient is small, high speed limit. However, the impact of intolerance, not suitable to withstand heavy loads. Deep groove ball bearings installed in the shaft, the axial clearance in the bearing within the housing limit the axis or axial displacement in both directions, so you can make in the two-way axial positioning.

    In addition, the class also have some bearing self-aligning capability, when compared to shell hole tilt 2 'to 10' would still work, but has some influence on bearing life. Deep groove ball bearing cage mostly steel stamping ribbon cage, large multi-use vehicles bearing metal solid cage. Deep groove ball bearings are widely used in automobiles, tractors, machine tools, motors, pumps, agricultural machinery, textile machinery, etc.



    Bearing number Size range Structure characteristic
    Bearing number Former bearing number Inner diameter Outer diameter
    6000 series 100 More than 30mm Less than 225mm Open and with seal or shield
    6200 series 200 More than 15mm Less than 400mm Open and with seal or shield
    6300 series 300 More than 15mm Less than 400mm Open and with seal or shield
    6400 series 400 More than 25mm Less than 340mm Open and with seal or shield

    Please download to find more detail information about Deep groove ball bearing
