Place of Origin: | China |
Brand Name: | TOB Sintered Parts |
Certification: | ISO 16949 |
Minimum Order Quantity: | negotiated |
---|---|
Price: | negotiated |
Packaging Details: | Cartons or Pallets |
Delivery Time: | negotiated |
Payment Terms: | T/T |
Supply Ability: | negotiated |
Material: | Bronze Or Iron Powder Sintered | Types: | Plain & Flanged Bushes, Self-aligned Bushes, Solid Rod, Plate, Sintered Bushes, Oilite Bushes, Self-lubricated Bushes, Sintered Bearings And Different Profile Components As Per Drawings / Samples |
---|---|---|---|
Applications: | Domestic Electric Appliance, Electric Tools, Textiles Machinery, Chemical Machinery And Automobile Industry, Etc. | Sequence Of Production: | Forming • Sintering • Sizing • Oil Impregnation |
Speed For Sintered Bronze: | Up To 18000 Rpm | Speed For Sintered Iron: | Up To 3000 Rpm |
Highlight: | sintered bronze bearings,sintered bronze bushing |
We are manufacturing and supplying sintered bushes parts with the following technical specifications:
With the obviously advantages, It is widely used in domestic electric appliance, electric tools, textiles machinery, chemical machinery and automobile industry, etc.
Sintered porous metal bearings are powder metallurgical parts, the starting materials are obviously metal powder. The metal powder used are specifically produced to give flow and compacting characteristic and at the same time ensure best mechanical strength, grade or porosity for oil retention and self-lubrication in its finished form.
Sequence of Production:
• Forming (or compacting)
• Sintering
• Sizing
• Oil Impregnation
Range:
• Plain & flanged bushes, self-aligned bushes, solid rod, plate, sintered bushes, oilite bushes, self-lubricated bushes, sintered bearings and different profile components as per drawings / samples.
Applications:
• Sintered bronze bushes are used for high speed application ( up to 18000 rpm)
• Iron Sintered bushes are used for speed (up to 3000 rpm)
Grade I, Copper Base
Elements | Class A% | B3% | B2% | B1% |
Iron (Fe) | 1.00 Max | 48-50 | 38-40 | 28-30 |
Tin (sn) | 8-9.5 | 4-6 | 4-6 | 4-6 |
Carbon (C) | 2.0 Max. | 2.0 | 2.0 | 2.0 |
Impurities | 2.0 | 2.0 | 2.0 | 2.0 |
Copper (Cu) | BAL. | BAL. | BAL. | BAL. |
Grade II, Iron Base
Self-lubricating Iron Sintered Parts is a more modified variety offered by us. It does not require external source of lubrication and is preferred over the other varieties, due to the convenience that it offers.
Elements | Class A% | B3% | B2% | B1% |
Copper (Cu) | 1.00 Max | 9-11 | 4-6 | 1.5-3.5 |
Carbon (C) | 0.25 Max. | 0.25 | 0.25 | 0.25 |
Impurities | 2.0 | 2.0 | 2.0 | 2.0 |
Copper (Cu) | BAL. | BAL. | BAL. | BAL. |
